Sinotruk HOWO Manufacturer Weichai 10 Wheel 6X4 8X4 371HP 400HP 430HP Heavy Duty Mining Cargo

After-sales Service: 24 Hours After-Sale Service Warranty: 1 Year or 50000km Which Comes First Vehicle Condition: Brand New Transmission Type: Manual Power: Diesel Load Capacity: 21-30t Emission Standard: Euro 2
Send Inquiry
Product Introduction



Quick delivery

Various logistics modes are available

Quality and Trust

High-quality products, first-class company reputation.

Secure payment

100% secure payment

24/7 Support

Dedicated support





Product Images

6X43



6X42



6X4



6X41



6X48



6X47



6X44



6X45





202011231449IMG4687



Product Description

Howo is a world class truck brand with first class capabilities and top technology, you can rely on Howo's technical prowess and product quality. This dump truck is suitable for the transportation of various bulk materials such as sand, earth, coal, ore, etc., with strong power.
     If you would like to know more details or are interested in this product, please feel free to contact me.





Sinotruk HOWO 6x4 Dump Truck

Chassis Model

ZZ3257M327W (Left/ Right Hand Driving Type Optional)

Engine

Model: WD615.47, Euro 2, 371 HP
6-cylinder in-line with water cooling, turbo-charging and intercooling
Displacement: 9.726 L

Clutch

Single-plate dry diaphragm spring clutch,diameter430mm,hydraulically operating with air assistance

Gearbox

SINOTRUK BRAND, manual operation, HW19710, 10 forward and 2 reverse, with Power Take-Off (PTO)

Front Axles

HF9, 9000kg with drum brake system

Rear Axles

HC16, 2X16000kg, double stage reduction (central+ hub), cast axle housing, ratio: 5.73

Suspension

Front suspension: 10 pcs leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer

Rear suspension: 12 pcs leaf springs with bogie spring and stabilizer

Steering System

ZF brand power steering, model ZF8118 , hydraulic steering with power assistance

Braking System

Front drum rear drum brake, four-circuit protection valve

Service brake: dual circuit compressed air brake

Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake (optional): engine exhaust brake(EVB), antilock brake system (ABS), automatic brake gap adjustment arms

Tires

12.00R20 (12.00-20, 315/80R22.5 optional), with one spare tyre

Fuel Tank Volume (L)

300

Dead Weight

12020/8630

Gross Vehicle Weight (kg)

25000

Rated Loading Weight (kg)

12850; 12640 optional

Overall Dimension

(LxWxH) (mm)

7545x2550x3400

Wheelbase (mm)

3225+1350

Min.Ground Clearance (mm)

314

Approach/Depart Angle(°)

19/ (27/65)

Gradeability (%)

≥50

Min. Turning Diameter (m)

15

Cargo Body Size (LxWxH) (mm)

4800x2300x1200

Cargo Body Volume (m3)

13.25

Remark (Engine Power Option)

336HP; 371HP
